Product description
Shell® ROTELLA T5 15W-40 is a synthetic blend heavy duty diesel engine oil featuring "Low-SAPS" additive technology for increased compatibility with the latest exhaust emissions control systems while delivering energy savings. Protective power is further enhanced through the use of synthetic base oil technology that increases additive activity.
The advanced formulation delivers good engine cleanliness and protection against piston deposits, ensuring engine and component reliability at extended oil drain intervals.
Product typeSynthetic Blend Heavy Duty Diesel Engine Oil
SAE viscosity grade15W-40
API service categoryCK-4, CJ-4, CI-4 Plus, CI-4, CH-4
Main applications
Low emission engine use — meets the requirements of major US and European engine manufacturers
On- and off-highway heavy duty diesel engines, including the latest emission-controlled engines using EGR and Diesel Particulate Filters
Agricultural, mining, logging, and construction applications, even with high levels of fuel sulfur
Specifications, approvals & recommendations: API CK-4, CJ-4, CI-4 Plus, CI-4, CH-4; ACEA E9, E11; Caterpillar ECF-3, ECF-2; Cummins CES 20086, 81; Detroit Fluids Specification (DFS) 93K222, 93K218; Deutz DQC III-10 LA; JASO DH-2; Mack EOS-4.5, EO-O Premium Plus; MAN M 3575; MB-Approval 228.31; MTU Category 2.1; Volvo VDS-4.5, VDS-4; Ford WSS-M2C171-F1.
Typical physical characteristics
SAE viscosity grade15W-40
Kinematic viscosity @ 40°C111.2 mm²/s
Kinematic viscosity @ 100°C14.9 mm²/s
Dynamic viscosity @ -20°C6,200 mPa·s
Viscosity index138
Total base number (TBN)8.5 mg KOH/g
Sulphated ash1.0%
Density @ 15°C0.873 kg/l
Flash point (COC)251°C
Pour point-37°C
These characteristics are typical of current production. Whilst future production will conform to Shell's specification, variations in these characteristics may occur.
Performance, features & benefits
Energised protection
"Low-SAPS" additive technology increases compatibility with the latest exhaust emissions control systems while delivering energy savings.
Enhanced protective power
Synthetic base oil technology increases additive activity to deliver fuel economy benefits over conventional 15W-40 oils.
Improved engine cleanliness
Good engine cleanliness and protection against piston deposits ensure engine and component reliability at extended oil drain intervals.
Health, safety & handling
Shell® ROTELLA T5 is unlikely to present any significant health or safety hazard when properly used in the recommended application and good standards of personal hygiene are maintained. Avoid contact with skin; use impervious gloves with used oil, and wash immediately with soap and water after skin contact.
Consult the applicable Shell® Safety Data Sheet (SDS) before handling, storing, or using this product.
Available packaging
5-gallon pails
55-gallon drums
Totes / IBCs
Bulk
Packaging availability may vary. Contact Miles Lubricants LLC for current packaging and minimum-order requirements.
Product information
Miles Lubricants LLC
Industrial lubricants, chemicals, and specialty fluids
Product
Shell® ROTELLA T5 15W-40 (5 Gal Pail)
SAE grade
15W-40
API category
CK-4, CJ-4, CI-4 Plus, CI-4, CH-4
For product availability, technical information, and Safety Data Sheets, contact Miles Lubricants LLC.
Disclaimer
The information and typical properties contained in this Product Data Sheet are provided for general informational purposes and are believed to be accurate at the time of publication, based on published Shell technical literature for ROTELLA T5 15W-40. Typical values are not specifications or guaranteed properties. Product users are responsible for determining the suitability, compatibility, safety, and regulatory compliance of the product for their particular application. Please consult the applicable Safety Data Sheet before use.
